SC APC to SC UPC Fiber Patch Cord Single Mode Simplex LSZH Cable
Product Introduction:
SC/APC to SC/UPC fiber optic patch cord is designed for high-speed and stable data transmission, using 9/125µm single-mode fiber with factory-terminated connectors for reliable performance.
Key Features:
SC/APC to SC/UPC connectors
9/125µm single-mode simplex fiber
LSZH 3.0mm jacket for safe indoor use
Low insertion loss and high return loss
100% factory tested with QC traceability
Available in 1m 2m 3m lengths
Applications:
Optical Characteristics
|
Parameter |
PC |
UPC |
APC |
Multi-mode |
|
Insertion loss |
≤0.3dB |
≤0.3dB |
≤0.3dB |
≤0.3dB |
|
Return loss |
≥40dB |
≥50dB |
≥60dB |
≥35dB |
|
Exchange |
≤0.2dB |
|||
|
Repeatability |
≤0.2dB |
|||
|
Servicelife |
>1000times |
|||
|
Tensile strength |
>10kg |
|||
|
Temperature range |
-40°C to +85°C |
|||
Technical Data
|
Type |
Standard,Master |
|
Style |
LC,SC,ST,FC.MU,DIN,MPO,SC/APC,
FC/APC,LC/APC.MU/APC |
|
Fiber |
Singlemode/Multimode
50/125,62.5/125(Multi mode) OM2&OM1
50/125,10G(Multi mode)OM3 |
|
Cable |
Simplex,Duplex
outer diameter:3.0mm,20mm,0.9mm
PVC or LSZH |
|
Polishing Manner |
UPC,SPC,APC(8°&6°) |
|
Insertion Loss |
≤0.1dB (For Single mode Master)
≤0.25dB (For Single mode Standard)
≤0.25dB (ForMultimode)
Tested by JDSRM3750 |
|
Return Loss (Single mode) |
UPC≥50dB
SPC≥55dB
APC≥60dB (typ.65dB)
Tested by JDSRM3750 |
|
Repeat ability |
≤0.1dB |
|
Operating temperature |
-400 C° to 850 C° |
|
Geometry Requirement (Single mode) |
Ferrule Endface Radius
7mm≤R≤12mm (For APC)
10mm≤R≤25mm (For Standard)
Apex Offset≤30μm (For Master)
Apex Offset≤50μm (For Standard)
Under cut-50nm SU≤50nm
Tested by DORCZX-1 |
Connector Type
Recommed Products
Packing & Delivery
Packing:100/Pcs in one Carton box or OEM.
Shipment:by Sea,by Air,by Express:DHL/UPS/Fedex/EMS/TNT etc
Deliverty: 3-5 days after payment dowm,According to ur order quantity.
Factory Pictures
Fiber Patch Cord FAQ
Q1: What connectors does this patch cord use?
A: It uses SC/APC to SC/UPC connectors.
Q2: What type of fiber is included?
A: 9/125µm single-mode simplex fiber.
Q3: Is it suitable for indoor use?
A: Yes, it has an LSZH jacket for safety and low smoke.
Q4: What lengths are available?
A: 1m, 2m, and 3m options.
Q5: Is the cable tested before delivery?
A: Yes, it is 100% factory tested for performance.
